Aluminum Sliding Wooden Partition Walls For Living Room / Hotel

Name: Aluminum Sliding Wooden Partition Walls For Living Room Hotel
Brand: BANGE
Price: 1 USD

Quality Aluminum Sliding Wooden Partition Walls For Living Room / Hotel wholesale

Brand Name : BANGE

Model Number : 85 mm wooden partition walls

Certification : ISO9001

Place of Origin : Guangdong

MOQ : 10 square meters

Price : US Dollars 80 - 120 per square meters

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 50000 square meters per month

Delivery Time : 15-20 days

Packaging Details : Carton package, MDF batten on four section sides , foam board on both front face.

Color : Accept customized

Application : Hotel,banquet hall

Panel width : 500 mm--1230 mm

Door material : Melamine board

Surface : Leather

Position : Interior

Size : 85 mm(3 1/4 inch)

Open style : Sliding

Feature : Sound insulation

Product name : Wooden partition walls

Contact Now

China Hotel Aluminum Sliding Movable Wooden Partition Door Sliding Wall

Product Details:

Model	Weight (kg/m)	Fire Rating(min)	STC Performance	Specification
Model	Weight (kg/m)	Fire Rating(min)	STC Performance	Thickness (mm)	Width(mm)	Height(mm)	Top Seal(mm)/ Pressure(kg)	Bottom Seal(mm)/ Pressure(kg)	LCP stretch (mm)
BG65-32	22	60	32db	65	680-1212	2000-4500	22.5/35	22.5/35	140
BG65-38	27	60	38db	65	680-1212	2000-4500	22.5/35	22.5/35	140
BG65-45	35	60	45db	65	680-1212	2000-4500	22.5/35	22.5/35	140

The movable wooden partition wall system is tongue-and-groove unitized panel system. Panels are precision laminated, pre-finished with vinyl, fabric or other specified finish. All vertical and horizontal structural members consist of extruded aluminum components, with a snap-on base made of extruded vinyl. Panels lift into floor and ceiling tracks to form a rigid, uniform wall system that provides excellent sound transmission resistance with a STC rating of 35 to 58dB.

1. You can divide a big space into smaller spaces as you wish with this partition.
2. Sound insulation coefficiency: 30~55dB.
3. height: 3m-7.5m
4. thickness: 65mm/80mm/100mm
5. base Material: sound absorbent cotton, sound insulation cotton, sound insulation rubber, etc.
6. frame: It's frame is made of strong and light weight aluminum.
7. surface veneer: MDF panel, fabric panel, acoustic panel, etc.
Aluminum Sliding Wooden Partition Walls For Living Room / Hotel
Specifications:

■ 65mm thickness panel ,Max height up to 4500mm.

■ Top supported without floor track or guide.

■ Clear anodized extruded aluminum tracks and frames,customized powder coated color are available.

■ Sound insulation coefficien :STC 32db to 45db, ASTM standard of acoustic tested in HongKong.

■ Available in wide range of finishes.

■ Fast delivery and Rich experiences in oversea project installation guide & supervision.

Competitive Advantage:

“One-stop building materials supply” Service.

Our experienced designer and engineers are familiar with your building code, and can always find the best solution for you.

All of our products are customized.

There are many choices to meet your various requirements.

No MOQ restriction.

Much experience to work for all kinds of projects.

Save your valuable time and purchasing cost.
Aluminum Sliding Wooden Partition Walls For Living Room / Hotel

Series	BG65	BG80 / BG85	BG100 & BG125
Panel suspension	Top hung only	Top hung only	Top hung only
Track system	Single or twin point	Single or twin point	Single or twin point
Panel thickness	65mm	80mm / 85mm	100mm
Panel height	Up to 4000mm	Up to 6000mm	Up to 18000mm
Max height	4000mm	6000mm	18000mm
Panel width	600-1230mm	600-1230mm	600-1230mm
Frame construction	Aluminum frame	Aluminum frame	Aluminum frame
Face material	9mm	9mm / 12mm	12mm
Fire safety	Optional Class I or O	Optional Class I or O	Optional Class I or O
Vertical profiles	Aluminum anodised with sealing profiles	Aluminum anodised with sealing profiles	Aluminum anodised with sealing profiles
Retractable seals	Aluminum black with double rubber seals	Aluminum black with double rubber seals	Aluminum black with double rubber seals
Operation of seals	Manual, with supplied operating handle	Manual, with supplied operating handle	Manual, with supplied operating handle
Locking	Optional lock to pass doors	Optional lock to pass doors	Optional lock to pass doors
Pass doors	Single open in panel or double open in two panel	Single open in panel or double open in two panel	Single open in panel or double open in two panel
Sound insulation	20-32dB Rw	28-36dB Rw	32-50dB Rw
Weight	Approx 22-35kg/sq M	Approx 25-40kg/sq M	Approx30-48kg/sq M
Finish Material	Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc.(Customized)

Common Applications:

BUNGE soundproof movable partition wall can be used to Convention Centers, Gymnasiums, Religious Facilities, Hotels, Auditoriums, Corporate Training Facilities, Civic or Exposition Halls, Schools, Banquet Facilities, etc.

With movable partition wall systems, there are no more barriers to maximizing the potential of your available building spaces.

Aluminum Sliding Wooden Partition Walls For Living Room / Hotel
