Conference Hall Removable Acoustic Wall Sliding Folding Partition For Banquet Room

Guangdong Bunge Building Material Industrial Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Conference Hall Removable Acoustic Wall Sliding Folding Partition For Banquet Room

Brand Name : EBUNGE

Model Number : 65 mm sliding folding partition

Certification : ISO9001

Place of Origin : Guangzhou, China

MOQ : No MOQ, small quantity welcomed

Price : US $78-95 per square meter

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 50000 square meters per month

Delivery Time : 12-20 days

Packaging Details : Paper carton, outside with wooden boxes

Product name : Sliding folding partition

Application : Banquet room partition

Size : Partition walls customized

Thickness : 65 mm(2 9/16 inch)

Frame material : Aluminum alloy

Advantages : Sound proofing

Contact Now

Conference Hall Removable Acoustic Wall Sliding Folding Partition for Banquet Room

Sliding folding partitions details

1) When moving a sliding folding partition wall panels, there is a 20-25mm gap between the top of the panel and the underside of the head track, there is a similar gap between the bottom of the panel and the floor.

2) Once a sliding folding partition walls panel is positioned, acoustic integrity is maintained along the top and bottom of the panel by extending pressure seals.

3) The pressure seals are extend and retracted by a single 180 degree turn of removable operating handle.

4) Final Closure of the sliding folding partition wall is achieved by extending a telescopic sleeve on the last panel. This action simultaneously extends the top and bottom seals.

5) As you know, when we do not use the sliding folding partition walls, we can park them to the parking area. Actually there are many parking styles for the sliding folding partition walls, all of the clients can choose the suitable one and we can adjust based on their own project site. If you need some pocket doors to hide the panels, BUNGE Factory also can produce for you.

Conference Hall Removable Acoustic Wall Sliding Folding Partition For Banquet Room Conference Hall Removable Acoustic Wall Sliding Folding Partition For Banquet Room Conference Hall Removable Acoustic Wall Sliding Folding Partition For Banquet Room

Technical Information

Model BG-65 series BG-85 series BG-100 series BG-high series
Suspension system Aluminum hanging Aluminum hanging Aluminum hanging Steel hanging
Basic thickness 65mm 85mm 100mm 100mm
Total thickness 65/75/85/95mm 85/90/100/110mm 100/120/130mm 100/120/130mm
Max height Up to 3800mm Up to 4500mm Up to 6500mm Up to 12000mm
Width 600-1230mm 600-1230mm 800-1230mm 800-1230mm
Floor/ceiling sealing strength Telescopic aluminum tube with rubber strip
Side walls sealing strength Double seal tape
Sound insulation level 26dB-30dB 28dB-34dB 32-40dB 32-40dB
Panel structure Aluminum frame with wooden keel Aluminum frame with steel keel
Panel density 22-28kg/sqm. 24-32kg/sqm. 32-50kg/sqm. /
Surface material Melamine laminate/fabric/PU leather/wallpaper/veneer/customized

Conference Hall Removable Acoustic Wall Sliding Folding Partition For Banquet Room

Sliding folding partition FAQ

1) Sliding folding partition walls interlocking male / female trapezoidal vertical aluminium profiles, for soundproof connection between elements.

2) To ensure additional friction connection, sliding folding partition wall panels shall be integrated with magnetic strip.

3) Sliding folding partition walls spring load retractable sound seal at the top and bottom element.

4) Face panel hung in sliding folding partition walls free suspension, for improved sound insulation, easy redecoration of surface panels. Edges shall be protected with Aluminium profiles.

5) Easy element adjustment after installation.

Conference Hall Removable Acoustic Wall Sliding Folding Partition For Banquet Room

We Offer:


◆ A full professional design service.


◆ Survery and installation guide.


◆ Using top quality materials and components.


◆ A fully experienced work team.


◆ Maintenance contracts to ensure your valuable asset remains in full work order.
